ST270 5.0 Braided aluminum alloy data cable 60W Type-C to Type-C /30W Type-C to Lightning

ST270 5.0mm Thickened Braided Aluminum Alloy Fast Charging Data Cable

Product Overview
The ST270 series is a high-performance braided data cable featuring a 5.0mm thickened cable diameter design. Combining a reinforced internal wire structure and precision aluminum alloy connectors, it is built for users who prioritize stable high-current transmission and exceptional durability. This series offers four independent connector models: USB to Lightning/Micro/Type-C, Type-C to Type-C, and Type-C to Lightning. Each model is available as a separate SKU, allowing users to precisely select based on their device requirements.

Key Specifications

• Length: 1 meter

• Cable Diameter: 5.0mm (thickened and reinforced design)

• Material: High-density braided outer layer + Aluminum alloy connector housing

• Colors: Classic Black / Simple White

• Internal Wire Structure:

• USB to Micro/Lightning/Type-C variants: (43/0.08BS+250D)*2C + (10/0.08BS+250D)*2C

• 60W Type-C to Type-C / 30W Type-C to Lightning variants: (55/0.08BS+250D)*2C + (16/0.08BS+250D)*3C

Performance Specifications

• USB to Micro/Lightning/Type-C Variants: Support 5V/2.4A (12W) charging and data transfer

• 60W Type-C to Type-C Variant: Supports 20V/3A (60W) PD fast charging

• 30W Type-C to Lightning Variant: Supports 9V/3A (30W) fast charging

• Full Series Functionality: All variants support simultaneous charging and data transfer

Key Selling Points

1. 5.0mm Thickened Cable Diameter Design

• Adopts an industry-leading 5.0mm large cable diameter structure, providing ample internal space to effectively reduce resistance and heat generation.

• Supports prolonged high-power transmission, with a temperature rise approximately 35% lower than standard cables during 60W full-load operation.

• Full and sturdy cable body offers a substantial feel and stronger physical damage resistance.

2. High-Density Braided Reinforcement Process

• 96-strand high-density braided outer sheath provides excellent resistance to stretching, wear, and tangling.

• The braided layer is treated for anti-static and water-splash resistance, adapting to various usage environments.

• Features a fine, uniform surface texture that balances aesthetics and functionality.

3. Precision Aluminum Alloy Connectors

• Connectors are made from 6063 aviation-grade aluminum alloy using CNC one-piece molding, with an anodized surface finish.

• Gold-plated internal contacts ensure high conductivity, with a plug/unplug lifespan of ≥10,000 cycles.

• Four-layer injection molding reinforcement at the junction between connectors and cable body effectively prevents breakage risks.

4. Intelligent Fast Charging with Full Compatibility

• Automatically recognizes device types and intelligently matches mainstream fast-charging protocols such as PD3.0, QC4+, and AFC.

• Supports fast charging and data transfer for various devices, including smartphones, tablets, and laptops.

Use Cases

• Gaming phones and devices requiring high-current transmission.

• Office and creative scenarios with long-term high-load usage.

• Environments demanding high cable durability, such as car charging and power banks.

• Professional users and enthusiasts seeking reliability and stable performance.

Technical Features

• DC Resistance: <0.08Ω/m

• Rated Current: 5A (Max)

• Operating Temperature: -30°C to 70°C

• Tensile Strength: ≥100N

• Bend Life: ≥15,000 cycles

Usage Recommendations

1. For optimal 60W fast charging performance, use with a PD charger rated ≥65W.

2. When storing, avoid sharp-angle bends; using a cable winder with a diameter ≥8cm is recommended.

3. Regularly clean the metal contacts of the connectors to maintain good conductivity.

4. Avoid prolonged use in humid environments to prevent affecting internal insulation performance.
