ST247 Transparent data cable 60W Type-C to Type-C /30W Type-C to Lightning

ST247 Transparent Braided Aluminum Alloy Data Cable

Product Overview
The ST247 series is a high-performance data cable featuring a transparent braided exposed design and aluminum alloy connectors, perfectly integrating the internal precision wire structure with modern industrial aesthetics. It provides stable fast charging and data transfer while showcasing a unique transparent technological beauty. This series offers four independent models: USB to Lightning/Micro/Type-C, Type-C to Type-C, and Type-C to Lightning. Each model is available as a separate SKU, allowing users to choose flexibly based on their device needs.

Key Specifications

• Length: 1 meter

• Material Structure: High-transparency TPU outer layer + Colored braided inner layer + Aluminum alloy connectors

• Colors: Midnight Black / Crystal White / Flame Red / Deep Sea Blue

• Internal Wire Structure:

• USB to Micro/Lightning/Type-C variants: (43/0.08BS+250D)*2C + (10/0.08BS+250D)*2C

• 60W Type-C to Type-C / 30W Type-C to Lightning variants: (55/0.08BS+250D)*2C + (16/0.08BS+250D)*3C

Performance Specifications

• USB to Micro/Lightning/Type-C Variants: Support 5V/2.4A (12W) charging and data transfer

• 60W Type-C to Type-C Variant: Supports 20V/3A (60W) PD fast charging

• 30W Type-C to Lightning Variant: Supports 9V/3A (30W) fast charging

• Full Series Functionality: All variants support simultaneous charging and data transfer

Key Selling Points

1. Transparent Braided Perspective Aesthetics

• Uses an 85% high light transmittance TPU outer layer, with the internal colored braided structure clearly visible, creating a three-dimensional layered effect.

• The four main colors correspond to the inner braiding colors, forming an inside-out color coordination system.

• The material is certified with Grade 5 anti-yellowing properties, maintaining crystal clear transparency even with long-term use.

2. Aluminum Alloy Precision Industrial Design

• Connectors are made from CNC-machined 6061-T6 aluminum alloy with micro-arc oxidation surface treatment, achieving a hardness of HV500.

• The transparent housing and metal connectors are joined using ultrasonic welding technology, resulting in seamless and aesthetically pleasing connections.

• Weight distribution is carefully calculated to provide a solid, quality feel during plugging and unplugging.

3. Dual-Core Parallel Transmission Architecture

• Features a dual-channel independent shielding structure to prevent interference between power transmission and data signals.

• Supports USB 2.0 data transfer standard with a transfer rate of 480 Mbps.

• The braided layer is woven using a 32-spindle precision braiding machine with a density of 1200 meshes per square inch.

4. Intelligent Temperature Control Protection System

• Built-in NTC temperature sensor for real-time monitoring of connector operating temperature.

• Automatically adjusts output power when the temperature exceeds 55°C to ensure safe usage.

• Aluminum alloy connectors offer excellent heat dissipation, with a full-load operating temperature difference of <15°C.

Use Cases

• Tech-inspired decor for gaming desktop setups.

• Visual displays in digital product showcases.

• Modern-style accessories for creative studios.

• Live demonstrations at tech exhibitions and product launches.

Technical Features

• Light Transmittance: ≥85% (ASTM D1003 standard)

• Braiding Angle: 45° diagonal weave

• Operating Temperature: -30°C to 70°C

• Connector Plug/Unplug Force: 15N±3N

• Sweat Corrosion Resistance Rating: Grade 5 (GB/T 3920)

Usage and Care Guide

1. Use dedicated transparent cable cleaner to maintain surface transparency.

2. Avoid contact with organic solvents and sharp objects.

3. When storing, use an individual cable pouch to prevent surface scratches.

4. For long-term storage, keep away from light and moisture to maintain optimal transparency.
